eBike Features
Collapsible content
See Full eBike Specifications
Top Speed:
25 MPH on pedal assist, 20 MPH on throttle (Class III eBike)
Motor:
Shengyi rear hub, 48V, 500W
Battery:
672 Wh (48V, 14 Ah) with LG cells
Sensors:
Cadence, Speed
Throttle:
Thumb throttle, left side
Display:
Denago high-resolution LCD with speed, trip distance, odometer, trip time, battery charge level, and walk mode functions; plus integrated front and rear light controls.
Charger:
Multi-voltage 110-240V, 3A Fast Charger with USA plug
Safety Data Sheets (SDS):
Denago safety data sheets are available upon request via email.
COMPONENT HIGHLIGHTS
Collapsible content
See Full Component Specifications
FRAME AND FORK
Frame:
6061-T6 Aluminum Alloy, Step-thru style, Folding
Fork:
Rigid
Kickstand:
included
DRIVETRAIN
Pedals:
Folding, 9/16” with reflectors
Crankset:
Aluminum alloy, 170mm, 48 tooth chainring, with chainguard
Bottom Bracket:
Sealed, square taper, English thread
Rear Derailleur:
7 speed
Freewheel:
Shimano CS-HG200-7, 7 speed, 12-32 teeth
Shifter:
7 speed with optical gear display
Chain:
KMC Z7, 3/32”
COCKPIT
Handlebar:
Zoom, aluminum alloy, 25.4mm diameter, 620mm long
Grips:
Black rubber, lock-on style
Stem:
Zoom aluminum alloy, 25.4mm clamp, 1 ⅛” threadless, adjustable height, folding
Headset:
1 ⅛”, sealed, threadless
Saddle:
Denago Comfort
Seatpost:
Zoom aluminum alloy, 34.9mm diameter, 347-552mm telescopic
Seatpost Clamp:
Zoom, quick release
BRAKES
Levers:
Jak mechanical disc brake with motor cut-off
Calipers:
Jak mechanical disc brake
Rotors:
180mm, 6 bolt type
WHEELS
Tires:
20x3", anti-puncture, safety reflective stripe, eBike-rated
Tubes:
20x3", schrader valve
Rims:
Aluminum Alloy, 36 holes, 20"
Hubs:
Front - Joytech nutted, 36 holes, disc brake
Rear - Shengyi, nutted 36 holes, disc brake
Spokes:
Front - 36 Black 13 gauge spokes
Rear - 36 Black 12 gauge spokes
Nipples:
Brass
DIMENSIONS WHEN FOLDED
Just 20" wide, 35" long, and 30" tall
WEIGHT AND PAYLOAD
Complete eBike with battery:
62 lbs
Maximum rider weight:
300 lbs
Maximum cargo capacity:
35 lbs on the included rear rack
20 lbs on the optional head-tube mounted front rack, if installed
WHAT'S IN THE BOX
Complete eBike
Keys
Lithium-Ion battery
3 Amp fast charger
Quickstart guide
Wheel reflectors
Assembly Tools (pedal wrench, multi-tool)
COVID-19 has created specific challenges in the bicycle industry, especially around the availability of the components required to manufacture eBikes. As a result, we reserve the right to make substitutions of equivalent components of equal or better value to ensure we can consistently deliver our eBikes in a timely fashion. Thanks for understanding!
Size and fit
VIDEO REVIEWS OF THE FOLDING 1
Collapsible content
Full geometry chart and dimensions

Our size and fit recommendations
The Folding 1 fits most riders 5'1" - 6'5".
Always wear a helmet, and ride only where safe, legal, and appropriate.
Assembly tools included
Shipping and delivery
-
Free standard shipping on all eBikes
All eBikes ship free from Denago.com.
-
Fast delivery
In-stock eBikes are delivered in just 1-5 business days, depending on your state.
-
Need it today?
Check partner bike shops near you who sell assembled, ready to ride Denago eBikes. Find a dealer near you.
Documents for the Denago Fat Tire Step-thru eBike
DOWNLOADS
Geometry Chart
Denago Folding 1 eBike Geometry Chart
Last updated: Feb 7, 2023 (JPG)
Quick Start Guide
Denago Folding 1 eBike Quick Start Guide
Last updated: Feb 7, 2023 (PDF)
Owner's Manual
Denago Folding 1 eBike Owner's Manual
Last updated: Feb 3, 2023 (PDF)
Display Instructions
Denago Folding eBike K5242 Display Instructions
Last updated Feb 8, 2023 (PDF)
PRODUCT REVIEWS

Just got them
So far so good. The motor and the assist works well. Battery holds the charge. Easy to fold and unfold. Good balance for a bike that size. The question is will Denago stay in business will the dealers get parts if needed. It is such a new company that no one knows how the Wild West of E bikes will turn out.

The Folder
I like the bike a lot. Little on the heavy side but is to be expected. Rides comfortable and is convenient and fast. Love the bamboo luggage rack

Love this bike
Great bike, price, and value. Been looking for a folding e-bike and this one fit perfectly.

very fun Bike
The bike just arrived last week. Already have a 100 miles on it. Came completely assembled other then the pedals. Denago even included a multi-tool and pedal wrench to make the job of adding pedals supper easy. Battery was charge to over 70% so I did not even have to weight for a charge. At 6'2", the bike was very adjustable and is a very comfortable fit. The motor kicks into gear right away and I love the extra miles I can go. Overall, a very wise decision to invest in this Denago Bike. .....Love the head light and tail light for piece of mind.

Folding Bike
Well built at a fair price

Includes free 1 year subscription to Flare Premium ($60 value)
Every Denago eBike includes a free 1 year subscription to Flare Premium, ($60 value) the safety and tracking app for your iPhone or Android device.
With the Flare app, eBike riders can get incident detection (like a crash or fall), send a notification to your contacts automatically if you're unresponsive, send SOS messages, and and keep friends together on group rides.
